Reinforcement + Generative Optimization for Automated Software Testing with Generative AI (Optimizer Agent)
1
Objective
Design an Optimizer Agent that turns LLM-generated test cases into a high-coverage, low-redundancy, cost-aware test suite by closing the loop between generation → execution → learning.
2
Research Questions
RQ1. How effective is an Optimizer Agent (RL/Bandit/BO) at improving structural and mutation coverage versus prompt-only LLM generation?
RQ2. What reward formulation best balances coverage gain, bug discovery, redundancy reduction, and cost/time?
RQ3. Which optimization strategy (policy-gradient RL, contextual bandits, Bayesian optimization, or GA) gives the best quality-per-cost trade-off across projects of different sizes?
RQ4. How well do improvements generalize across repositories, languages, and test frameworks?
RQ2. What reward formulation best balances coverage gain, bug discovery, redundancy reduction, and cost/time?
RQ3. Which optimization strategy (policy-gradient RL, contextual bandits, Bayesian optimization, or GA) gives the best quality-per-cost trade-off across projects of different sizes?
RQ4. How well do improvements generalize across repositories, languages, and test frameworks?
3
System Overview
5-Stage Loop:
1. Generator (LLM + toolformer style context): Proposes test cases (unit/property/fuzz variants).
2. Executor (sandbox): Runs tests, collects coverage, failures, runtime, flakiness, mutants killed.
3. Selector/Memory: Deduplicates via similarity (AST + embeddings) and keeps a pool.
4. Optimizer Agent: Uses the feedback to choose the next generation action (prompt template, seed test to mutate, temperature, focus file/function, hypothesis strategy, fuzz budget).
5. Convergence: Stops when marginal gains fall below a threshold or budget exhausted.
1. Generator (LLM + toolformer style context): Proposes test cases (unit/property/fuzz variants).
2. Executor (sandbox): Runs tests, collects coverage, failures, runtime, flakiness, mutants killed.
3. Selector/Memory: Deduplicates via similarity (AST + embeddings) and keeps a pool.
4. Optimizer Agent: Uses the feedback to choose the next generation action (prompt template, seed test to mutate, temperature, focus file/function, hypothesis strategy, fuzz budget).
5. Convergence: Stops when marginal gains fall below a threshold or budget exhausted.
4
Reward Design
Let each iteration produce a batch (B) of tests. Compute per-batch signals:
• Coverage gain: ΔC = C_new - C_prev (line/branch/path), normalized to [0,1]
• Mutation gain: ΔM = (mutants killed_new - prev) / total mutants
• Failure discovery: F = unique failing assertions / |B| (de-duped by stack/trace hash)
• Redundancy penalty: R = mean cosine sim(emb(t_i), nearest in pool) ∈ [0,1]
• Cost/time: K = exec time_B / budget ∈ [0,1]
Multi-objective scalarized reward:
R(B) = α·ΔC + β·ΔM + γ·F - λ·R - μ·K
with (α+β+γ=1); tune (λ,μ) by budget.
• Coverage gain: ΔC = C_new - C_prev (line/branch/path), normalized to [0,1]
• Mutation gain: ΔM = (mutants killed_new - prev) / total mutants
• Failure discovery: F = unique failing assertions / |B| (de-duped by stack/trace hash)
• Redundancy penalty: R = mean cosine sim(emb(t_i), nearest in pool) ∈ [0,1]
• Cost/time: K = exec time_B / budget ∈ [0,1]
Multi-objective scalarized reward:
R(B) = α·ΔC + β·ΔM + γ·F - λ·R - μ·K
with (α+β+γ=1); tune (λ,μ) by budget.
5
Optimization Strategies
A. Contextual Bandits (fast, robust): Arm = "generation policy" (prompt + strategy), context = repo/file metrics; update via Thompson Sampling / UCB on R.
B. Policy-Gradient RL (fine control): State = coverage map + deficit hotspots; Action = generation knobs; Reward = R. Use PPO with action masking (invalid knobs pruned).
C. Bayesian Optimization (few but high-value steps): Black-box optimize R over continuous knobs (temperature, fuzz budget) + categorical (prompt template) via mixed-BO (SMAC/GP+TPE).
D. Genetic Search (diverse test pools): Evolve test cases and prompts; crossover = splice assertions & inputs; mutation = boundary value twists, fuzz seeds.
B. Policy-Gradient RL (fine control): State = coverage map + deficit hotspots; Action = generation knobs; Reward = R. Use PPO with action masking (invalid knobs pruned).
C. Bayesian Optimization (few but high-value steps): Black-box optimize R over continuous knobs (temperature, fuzz budget) + categorical (prompt template) via mixed-BO (SMAC/GP+TPE).
D. Genetic Search (diverse test pools): Evolve test cases and prompts; crossover = splice assertions & inputs; mutation = boundary value twists, fuzz seeds.
6
Dedup & Quality Gates
• Similarity filters: AST diff + semantic embedding (CodeBERT/UniXCoder). Drop if sim ≥ τ.
• Flakiness control: re-run failing tests (k) times; label flaky if fail/pass mix occurs.
• Invariant/Oracle quality: prefer property-based or metamorphic assertions when available; static analyzers to flag over-fitting assertions.
• Flakiness control: re-run failing tests (k) times; label flaky if fail/pass mix occurs.
• Invariant/Oracle quality: prefer property-based or metamorphic assertions when available; static analyzers to flag over-fitting assertions.
7
Datasets & Targets
• Small/medium: open-source libs with mature tests (e.g., utility/date/math libs).
• Large: 1–3 real-world repos (backend service, CLI tool).
• Languages: start with Python (pytest + Hypothesis) and one JVM repo (JUnit + PIT).
• Large: 1–3 real-world repos (backend service, CLI tool).
• Languages: start with Python (pytest + Hypothesis) and one JVM repo (JUnit + PIT).
8
Baselines
• B0: Prompt-only LLM tests (single pass).
• B1: Prompt + simple heuristic selection (keep unique filenames/lines touched).
• B2: Search-based testing (e.g., EvoSuite/PBT without LLM).
• Your methods: Bandit, RL (PPO), BO, GA.
• B1: Prompt + simple heuristic selection (keep unique filenames/lines touched).
• B2: Search-based testing (e.g., EvoSuite/PBT without LLM).
• Your methods: Bandit, RL (PPO), BO, GA.
9
Metrics
Effectiveness:
• Line/branch/path coverage; Δ vs baseline
• Mutation score (killed/total)
• Bugs found (unique failing tests / confirmed issues)
• Redundancy: avg nearest-neighbor similarity; unique lines/functions touched
Efficiency:
• Quality-per-cost: (ΔC/min), (killed mutants/$)
• Wall time & runs to reach 95% of best coverage (sample-efficiency)
Stability/Generalization:
• Flake rate; transfer (train choices on Repo A, apply to Repo B)
• Line/branch/path coverage; Δ vs baseline
• Mutation score (killed/total)
• Bugs found (unique failing tests / confirmed issues)
• Redundancy: avg nearest-neighbor similarity; unique lines/functions touched
Efficiency:
• Quality-per-cost: (ΔC/min), (killed mutants/$)
• Wall time & runs to reach 95% of best coverage (sample-efficiency)
Stability/Generalization:
• Flake rate; transfer (train choices on Repo A, apply to Repo B)
10
Experimental Design
• Phases: (i) Pilot on small repo to tune (α,β,γ,λ,μ). (ii) Full study across 4–6 repos × 3 budgets (time and $) × seeds (n=5).
• Ablations: remove each reward term; freeze generator (no knob changes); swap optimizer.
• Statistics: paired tests with Cliff's delta; bootstrap CIs; report Pareto frontiers.
• Stopping: no improvement of R for 3 iterations OR budget hit.
• Ablations: remove each reward term; freeze generator (no knob changes); swap optimizer.
• Statistics: paired tests with Cliff's delta; bootstrap CIs; report Pareto frontiers.
• Stopping: no improvement of R for 3 iterations OR budget hit.
11
Expected Contributions
1. Unified reward for coverage, mutation strength, failure discovery, redundancy, and cost.
2. Optimizer Agent design that adapts generation strategy to repo context.
3. Budget-aware evaluation showing quality-per-cost gains over strong baselines.
4. Reproducible toolkit (scripts + configs) to plug into CI.
2. Optimizer Agent design that adapts generation strategy to repo context.
3. Budget-aware evaluation showing quality-per-cost gains over strong baselines.
4. Reproducible toolkit (scripts + configs) to plug into CI.
12
Risks & Mitigations
• Oracle weakness → add mutation testing & metamorphic checks.
• LLM determinism → fix seeds & log prompts; use temperature schedules.
• Cost blow-ups → cap batch size, early-stop low-reward arms, use BO for expensive knobs.
• LLM determinism → fix seeds & log prompts; use temperature schedules.
• Cost blow-ups → cap batch size, early-stop low-reward arms, use BO for expensive knobs.
